Specifications
|
Model |
Length (L:mm) |
Motor Holding Torque (N.m) |
Current (A/Phase) |
Resistance (Ω) |
Inductance (mH) |
Motor Rotor inertia (g.cm2) |
Shaft diameter (D:mm) |
Shaft Extension (mm) |
Brake Torque (N.m) |
Weight (kg) |
Matched driver |
|
57HSB41A43006C |
72 |
0.6 |
3.0 |
0.7 |
1.4 |
120 |
6.35 |
Leveling block 0.5x20
|
1.3 |
0.85 |
JB542C |
|
57HSB51A43006C |
82 |
1.0 |
3.0 |
0.74 |
1.2 |
275 |
6.35 |
1.05 |
|||
|
57HSB56A43006C |
87 |
1.3 |
3.0 |
0.75 |
2.4 |
300 |
6.35 |
1.1 |
|||
|
57HSB56A43008C |
87 |
1.3 |
3.0 |
0.75 |
2.4 |
300 |
8.0 |
1.1 |
|||
|
57HSB76A44006C |
107 |
2.3 |
4.0 |
0.5 |
2.0 |
480 |
6.35 |
1.4 |
|||
|
57HSB76A44008C |
107 |
2.3 |
4.0 |
0.5 |
2.0 |
480 |
8.0 |
1.4 |
|||
|
57HSB85A44008C |
116 |
2.6 |
4.0 |
0.8 |
3.2 |
520 |
8.0 |
1.6 |
|||
|
57HSB115A44008C |
146 |
3.5 |
4.0 |
0.5 |
2.3 |
600 |
8.0 |
2.1 |
Note: The brake is DC24V power-off brake, other voltage can be customized as required
Dimension unit:mm
Wiring Diagram
Note:
When installing the motor, be sure to fix the position by using the front end cover of motor, and pay attention to the tolerance, strictly guarantee the concentricity of the motor shaft and the load.
